I have bought a SSD with M.2 socket (B & M) key, but my computer just have a B key socket. My question is if I can connect the SSD in this B socket, and would it work correctly?
Asked
Active
Viewed 5.0k times
13
-
1Are the B and M key on the picture not reversed? What is here named B key ( on the right) supports 4 pcie lanes – Annaray Jun 16 '18 at 11:11
-
The picture is from wikipedia, https://en.wikipedia.org/wiki/M.2 – kimo pryvt Jun 19 '18 at 22:23
2 Answers
10
It should... a B&M module should work with either a B or M socket, this is by design.
The B interface provides x2 PCIe, SATA, USB 2.0 and 3.0, audio, UIM, HSIC, SSIC, I2C, and SMBus support. The M interface provides x4 PCIe, SATA, and SMBus.
If your module is B&M SATA (most likely), connecting it to a B or M socket should work fine since both types support SATA.
Of course, being a bootable device is another story, this depends on your hardware and UEFI.
acejavelin
- 6,428
- 5
- 25
- 37
-6
No, you cannot. If the socket only have 1 keyed, then you have to only insert 1 keyed NOT B+M keyed m.2. i already tried, its not working.
Ric26
- 1
-
1Their SSD can be installed in a M.2 slot with a B or M slot. Their SSD absolutely is supported. – Ramhound May 07 '19 at 01:57
