Our bathtub has recently started draining very slowly (bathtub fills with water during a normal shower and takes a while to completely empty). This problem has coincided with winter, and I'm wondering whether it is possible that the drain pipe (maybe the bend in the pipe) in our crawlspace could be freezing?

We live in Boise, ID where it is not super cold in the winter, maybe 30s - 40s during the day, and in the 20s at night. The house was built in the 1940s, and the drain pipe is cast iron. It goes down into our crawlspace, which is uninsulated (just dirt covered with plastic lining on bottom of the crawlspace surrounded by the concrete foundation).

Does anyone know if there's a good way to determine this? And how we could remedy the situation? Would foam pipe insulation do the trick?

PS - no problems with other things in the house draining (sinks, washer).

Jason
  • 211
  • 2
  • 4
  • Did this happen "last winter"? – rogerdpack Jan 23 '19 at 18:47
  • Don't know @rogerdpack, just purchased the home in July – Jason Jan 23 '19 at 19:45
  • Just pour lye down the drain with no more than about a cup of standing water to prevent it from being flushed away before it works its magic. – Chloe Jan 23 '19 at 22:14
  • 1
    Cover the overflow with a wet rag and use a (real rubber, not that fluted plastic garbage) **plunger**. – Mazura Jan 24 '19 at 01:35
  • 3
    @Mazura + "vigorously" – Criggie Jan 24 '19 at 03:47
  • 2
    @Criggie + ["And go absolutely nuts with it."](https://diy.stackexchange.com/a/85183/23295) – Mazura Jan 24 '19 at 03:57
  • Does the water flow faster as the tub drains (implying the frozen area is thawing with the flow of water)? – Keeta - reinstate Monica Jan 24 '19 at 13:37
  • I actually forgot I made that answer. It was to be the end-all of questions about unclogging a pipe. Y'all gonna yell at me if I change the title to ***How do I unclog a bathtub?*** and mark this as a dupe? ;p – Mazura Jan 26 '19 at 00:25
  • *Does anyone know if there's a good way to determine this?* By having done your do diligence with a plunger before you call someone who actually knows how to use one. It's not rocket science ;) – Mazura Jan 26 '19 at 00:33

7 Answers7

13

It seems pretty unlikely that the drainpipe would freeze in your crawlspace. Even if there was a 20 degree wind whipping through it (which there isn't: it's enclosed), the only way that could be is if there was standing water in the pipe to freeze. That would mean a trap in the crawlspace which would be highly unusual. And if you really had a frozen pipe, it wouldn't drain at all.

Most likely you have a hairball in the drain. Try a "drain zipper" and/or a drain auger. When buying a hand auger, it's worth it to pay more for one with a toggle lock as opposed to a thumb screw. It will save you a ton of time and your hands will thank you.

JimmyJames
  • 1,881
  • 1
  • 13
  • 23
  • ok, we've tried a drain zipper and some other things in case it was a hairball or something but haven't had much success yet. maybe worth trying an auger. – Jason Jan 23 '19 at 17:05
  • I have pipes in my unheated basement. In very cold weather I have to shut off the supply lines or else they'll freeze. I've never had a drain freeze. I vote for a hairball as well. – Duston Jan 23 '19 at 17:05
  • 2
    @Duston Unless you drain the pipes, shutting them off isn't going to prevent freezing. In fact it can make it much more likely. Where I live (it got below 0F the last few days), people often have shutoffs inside for outdoor faucets. A common mistake is that people will shut them off without draining the faucet which basically guarantees it will freeze and likely burst between the shutoff and the faucet. By closing the valve you isolate the cold water. Below ground is basically always around 50F. An unheated basement should be roughly the same unless you have serious drafts. – JimmyJames Jan 23 '19 at 17:22
  • Yes, I do drain the pipes after I shut them off. And it's an old farm house...drafts are the norm. – Duston Jan 23 '19 at 17:50
  • @Duston That seems inconvenient. I'm recalling the farmhouse home of a friend growing up. It was really cold. In this case the OP is talking about a crawlspace with a foundation. It's hard to imaging it getting to freezing temperatures in that space being below freezing. – JimmyJames Jan 23 '19 at 17:59
  • Yes, it is a bit of a hassle, but less so than the mice. My point was that even when I've had supply lines freeze, I've never had a drain freeze, so the likelihood that OP's problem being a frozen drain is low. – Duston Jan 23 '19 at 18:18
  • @Duston Ah, I did miss your point. And every house has some mice eventually ;) – JimmyJames Jan 23 '19 at 18:22
  • The only thing I should probably add is that there are some open spots in the foundation (rectangular openings that just have screen covering them at the moment) – Jason Jan 23 '19 at 19:40
  • @Jason That does change things a bit but, especially at the temperatures you describe, I can't see how a drain would freeze. As Duston noted, your supply lines are more likely to freeze. – JimmyJames Jan 23 '19 at 22:17
  • @Jason I would recommend you have those openings permanently closed. There was once an idea that it was a good idea to ventilate under the house but it doesn't really work in practice. In the summer, the air will be warm and humid and come into the crawlspace where it's cooler and the air can't hold as much water. This can result in moisture and even mold issues in the crawlspace. In the winter, it's going to add to your heating bills. – JimmyJames Jan 23 '19 at 22:23
  • Cover the overflow with a wet rag and use a plunger – Mazura Jan 23 '19 at 23:09
  • @Jason One caveat about closing the openings in the foundation: if there are radon issues or similar in your area, you should get a test done before completely closing in the foundation. – JimmyJames Jan 24 '19 at 14:37
  • As someone who lives in a house where the bathtub drain does occasionally freeze, it is entirely possible. I'm not going anywhere near the claim that my house is typical or properly constructed, but If the tub is on the floor immediately above the crawlspace, where would it be normal to have the trap? – Mr.Mindor Jan 24 '19 at 17:46
  • @Mr.Mindor Under the subfloor but if it's that cold in the crawlspace, why wouldn't you have insulation under the floors? As noted in this and isherwood's answers, it's hard to imaging it "draining slow" in this situation. That implies warm water flowing past ice without melting it. When you drain freezes does it go slow or is it completely plugged? What temperature is it when this happens? – JimmyJames Jan 24 '19 at 18:00
  • Oh I completely agree that given the symptoms, it is very unlikely that freezing is the problem. Any flow, especially warm water through a partially frozen trap will _usually_ thaw it out. My comment was directed at your first sentence that is is unlikely that a drainpipe would freeze. Our crawlspace has a similar setup to what Jason describes with the vents. Standing water is the enemy here. We've learned to leave the tub trickling at anything below 32 degrees (there was one winter where it got around -20 for a few nights even a trickle wasn't enough and we woke up to a tub full of water.) – Mr.Mindor Jan 24 '19 at 18:32
  • First or second winter in the house I did actually install insulation under all the floors in the house. It was only after this that the bathtub drain first froze for us. The trap, where the ice blockages occur, extends below the floor joists (about 24 inches from the drain in the tub itself*), and insulating the floor (between the joists) prevented any warmth from the house from reaching it. I know the distance because after climbing through the crawl space with a space heater a couple times to thaw things out, I made an attachment for my shower head that allows me to (cont) – Mr.Mindor Jan 24 '19 at 18:51
  • (cont) thread a tube down the drain to deliver warm water directly to the ice. – Mr.Mindor Jan 24 '19 at 18:53
9

If that was the case the bathwater would melt the ice plug in short order (unless it was totally blocked). I suspect a common debris plug.

Also, it usually takes much colder weather to freeze things in a crawl space. Geothermal heat typically prevents it unless you have a lot of ventilation.

Cast iron corrodes and accumulates very hard crud over time. You may get away with a good hard auguring, but you may end up digging up the iron pipe and installing PVC or ABS. It's not usually a difficult job, access permitting.

isherwood
  • 119,766
  • 7
  • 148
  • 349
  • yeah I'm having a hard time imagining it could be freezing...my wife claims that it drained perfectly fine during a warm spell we had recently, so not sure what to make of that – Jason Jan 23 '19 at 17:03
  • 1
    Coincidences happen by the billions every day. :) – isherwood Jan 23 '19 at 17:15
  • 3
    I find when my tub clogs with hair/soap it will be just fine then reach a tipping point. It will drain as fast as I can pour water into the tub then basically not drain at all when one more hair is added to the jam. I just have to take some needle nose pliers and a flat head screw driver and pull everything out of the drain. All of the clog is usually easily accessible (even if it's kind of gross). If it's beyond the drain itself hopefully you have a clean out on the other side of the P-trap which would make things easier. – Brad Jan 23 '19 at 17:58
  • 1
    @Jason If you have trouble convincing the spouse, you could get a remote digital thermometer and tape it to the pipe. You can then see whether this is possible or if there is any variation. If it does get below freezing in the crawlspace, you should fix the drafts. You don't want cold air in there in the winter and you don't want warm humid air infiltrating in the cool crawlspace in the summer either. – JimmyJames Jan 23 '19 at 18:19
  • I guess you could heat up some water to "pretty warm" and pour it down...maybe? – rogerdpack Jan 23 '19 at 18:48
  • 1
    Could it be an obstructed *vent* with snow/ice on top that has it draining slowly? – R.. GitHub STOP HELPING ICE Jan 23 '19 at 23:48
  • *Correlation is not causation.* – Mazura Jan 26 '19 at 00:29
2

Here are some products that I have used for years and would recommend before spending a lot of money with a plumber.

Glug drain cleaner is a non-acid formula that works really well when you first experience a sluggish drain.

Glug Drain Opener

Crystal Heat is actually crystalized Sodium Hydroxide and Sodium Nitrate. You can't use this when there is standing water. Remove the drain stopper and pour about 1/4 cup down the drain and add a small amount of water. This stuff will boil and heat up to a point that it will actually melt grease and soap scum. It will also burn out hair clogs.

Crystal Heat Drain Opener

Finally, start using an active enzyme drain maintainer such as Tough Guy to help prevent future clogs.

Tough Guy Drain Maintainer

According to the respective manufacturers: Each of these products are safe for all plumbing applications and septic systems.

Jerry_Contrary
  • 3,665
  • 8
  • 24
  • 1
    Just my two cents: if you have old pipes, don't pour anything down them. I've deal with a drain waste that was rotted away from drain-o. The pipe wasn't draining properly so it sat there so YMMV but it's hard to know where this stuff will end up once you put it in. – JimmyJames Jan 23 '19 at 17:26
  • 1
    Another two cents...for those with septic systems, make sure these won't harm it – Duston Jan 23 '19 at 18:20
2

My thought here is that rather than a pipe being frozen, it might be a vent. This observation already appeared in a comment, but I think that it deserves the visibility of an answer. Also, I have more to say than is covered in the comment.

As several people have noted, an ice clog is unlikely to cause a slow drain. This is because the warm water would tend to melt the clog. However, that's not true of a vent. A vent would typically be a pipe running from your trap up through the house to the roof. As such, the part that would freeze would be at the other end from where the warm/hot water is. Further, a blocked vent can be entirely obstructed and water will still flow slowly, which is the problem that you're having.

This question has photos of a piece of internal venting, an air admittance valve connected to a drum trap. I'm talking about external venting, which would look similar at the trap connection end but the other end is outside. You might be able to see the trap connection from the crawlspace. Or not. If you can't see the top of the trap from the crawlspace, then you might not be able to see the venting either.

Here is someone who was having problems with a frozen vent pipe. There are no answers, but a comment helpfully points to this question on unfreezing pipes.

If this is the problem, you should be able to see a pipe rising from above the bathtub in the attic (assuming you have one). You might try wrapping it with heat tape and seeing if that gives the external vent (on the roof) enough warmth to melt off. As always, be careful about mixing electricity (the heat tape) with moisture (the cold vent pipe).

Note: I'm not saying that this is definitely the problem that you're having, nor that other ideas are wrong. I'm saying that this is one possibility that may be worth considering, as it would explain the observed behavior without resorting to coincidence.

A problem with venting might also be caused by snow coverage (rather than ice). Perhaps the air is being blocked by an accumulation of snow. A house that I rented once would have plumbing issues if a vent was covered by leaves or snow. So the landlord would first clear off the vent if there was a draining issue. That vent was in the ground, several feet from the house. So if you can't find a vent coming from the bathtub trap, you might look around for other parts of the vent stack that might be blocked.

Brythan
  • 211
  • 1
  • 5
  • Blocked vents do not cause slow drains. People always use the inverted soda bottle analogy, but that's not what happens at all, since there is no plumbing fixture in the world that has only 1 way in/out like a soda bottle - you'd have to vacuum-seal your toilet lid before flushing for a blocked vent to have any effect. Vents prevent P-trap siphoning, they don't do anything to help water go down the drain. Air already follows water down the drain, it doesn't need to pull any through the vent to equalize the pressure. – Nuclear Hoagie May 06 '20 at 16:54
1

You probably have an obstruction in the shower line or in the main line after all the pipes have come together in the stack.

One thing you can do is to access the stack main line and see if water is passing through by flushing the toilet or running the shower. If you see a good stream of water then the blockage is further downstream. If you see a trickle, then the blockage is upstream in the particular pipe which in this case is the shower.

If you see water going through the pipe then the blockage is downstream and could mean a frozen pipe or obstruction further down in the main line. Either case would be to snake to remove the obstruction or call a plumber to remove it.

Jon Raynor
  • 3,506
  • 3
  • 24
  • 28
  • I can't decipher what you're trying to say. – Hot Licks Jan 24 '19 at 00:38
  • @HotLicks - It reads pretty clearly to me. The obstruction is either before or after all the drain lines come together, so open the cleanout port where all the lines come together and see if there's good flow at the cleanout port. If there is, the obstruction is downstream, if there isn't, then it's upstream. – Chuck Jan 24 '19 at 16:12
  • So how do you know there is a cleanout port, and, if there is one, where it's located in the drain line? – Hot Licks Jan 24 '19 at 18:20
  • Every house should have a clean out port, however, it's location will be different. In my house, my pipes run under the basement floor and just before leaving the foundation perimeter there is a end cap on the basement floor for the clean out port. There should also be one when the main stack comes together as well. – Jon Raynor Jan 28 '19 at 17:24
1

I live in a house with a crawl space very similar to what you describe in the comments. If the drain lines are also built similarly to what I have, it is entirely possible for blockages to form from ice. (in particular in a trap.)

That said, I'm going to throw in with the others that given your symptoms, ice is unlikely the cause of your slow drain. Any water flow will cause the ice to melt and resolve any initial slowness (except in the coldest of temperatures, some rivers/streams do freeze over after all).

You can verify this by leaving the water running for a few minutes. If it starts slow then after several minutes drains normally, it might have been a partial blockage from ice.

If it behaves like this on a regular basis (starts slow then clears normally after a few minutes) then it may be a consistent issue, and you may benefit (like I did) from leaving the water on at a trickle to prevent standing water in the traps during the cold months.

Given your wife's claim that it wasn't a problem during a recent warm spell, I'm going to suggest another temperature based explanation for the behavior...

A lot of hair products particularly conditioners are oil based and will start to thicken/gum up if they get much below room temp. If you combine these with a drain line exposed to essentially outdoor weather changes in the crawl space, particularly if there are long horizontal runs, the line may be more prone to encourage 'normal' clogs like those described in other answers during winter months than it is at other times of year. Once a clog forms the advice given by others is the way to go to clear it, but, if you do over time see seasonal patterns in the behavior/likelihood of clogs you can take steps to help prevent them:

  1. Insulate the pipes. (insulated pipes will be quicker to adjust to the temp of the water flowing through them, and slower to return to the cold temp of the crawlspace)
  2. Use less product. (proper amount of product is more likely to rinse away cleanly and not have a chance to solidify in the drain.)
  3. Keep hot/warm water running for a few minutes before and after bathing. (keep the pipes above the coagulation temp of the product so it doesn't stick.)
Mr.Mindor
  • 111
  • 4
0

In addition to metal pipe corrosion as mentioned by @isherwood, there may also be mineral deposits if you have relatively hard water. This is especially common in horizontal runs of pipe -- and the longer the run, the more likely this is to be a problem.

Since mineral deposits will partially block the pipe, they also make the pipe that much more sensitive to the occasional debris plug. Unfortunately they also make the use of an auger much more difficult. I haven't personally tried a snare as recommended by @JimmyJames but my guess is that would have a higher chance of being effective than an auger (assuming the snare is long enough to reach the plug).

David
  • 101
  • 2
