I want to run internet from my main house to garage located few meters away. I plan to use fiber instead of cat5 to avoid reported problems of blowing out network switches.

I could have made a trench and placed fiber inside a conduit, however any shortest path from my house to garage (from attached garage where I plan to keep all my network equipment) is filled with concrete. I would need to break concrete to dig a trench.

Instead of digging the trench, could I pass fiber from under the roof of my house? The same way the electrical cable is passed right now.

isherwood
  • 119,766
  • 7
  • 148
  • 349
22332112
  • 153
  • 5

1 Answers1

5

Yes, absolutely.

The fiber you'll want for this job is "Drop" fiber - it's made to resemble (and work with the hardware for) telephone "drop" wire - and it's relatively inexpensive while being quite robust.

enter image description here

While we tend to knee-jerk away from aerial fiber because it's more exposed to damage, this is a perfectly viable solution.

However, for most home applications at this time, it's going to be much cheaper/easier and adequately effective (not really as fast as fiber, but probably faster than your internet feed unless you have gigabit fiber to your house) to use a 5 GHz "ac" "Point to Point" radio link between the buildings.

Ecnerwal
  • 174,759
  • 9
  • 212
  • 440
  • I agree with the alternative suggestion to go wireless. I've bee reading up on the new wifi "mesh" networks, and they almost seem like the holy grail of home networking. – isherwood Jun 26 '17 at 14:12
  • 2
    Honestly, as a network guy who does a lot of wireless, the holy grail is a lot of wires in the house and fibers between buildings. Among other things, they make the WiFi you do need to run for end-use devices that don't have a plug faster and more reliable. But a good mesh implementation can be a moderately blessed grail that will get the job done good enough, with much lower barrier$ to entry. Wires/fibers still beat the snot out of wireless for moving data efficiently, particularly with walls in the way. ;^) – Ecnerwal Jun 26 '17 at 16:18
