17.10 Display Settings - Missing Apply Button

Question

Just upgraded from 17.04 to 17.10 on a Dell laptop with a DisplayLink dock. I've reinstalled the latest 1.4 DisplayLink drivers - but I'm not sure this is a DisplayLink issue (Maybe it is). I'm also using the latest NVidia 384.90 driver.

When I make changes to my monitor scaling and position/order - I don't have get an Apply button. If I remove the laptops connection to the dock (and reboot) I do get the expected green Apply button in the top right hand corner after making changes.

Anyone have any idea where to start looking for a solution? I looks like there are people on the DisplayLink forums using 17.10 with the 1.4 driver - but again I'm not convinced this is a DisplayLink issue.

I tried logging back into a Unity session, but cannot make any changes to displays over there I get an error about not being able to read the monitor configuration.

When I run `gnome-control-center display` and change the scale of my HDMI monitor I get: "(gnome-control-center:6990): display-cc-panel-WARNING **: Config not applicable: GDBus.Error:org.freedesktop.DBus.Error.InvalidArgs: Logical monitor scales must be identical" — Steven Almeroth, Jan 22 '18 at 15:31
Had this issue on Ubuntu 18.04, Ended up finding the same options in the NVIDIA X server settings application, under X Server Display Settings Configuration and was able to change them there. — Jake, Dec 04 '18 at 16:29

score 1 · Accepted Answer · edited Oct 25 '17 at 21:49

1

Whether or not it is the proper solution, I downloaded ARandr to modify Xrandr settings and was able to set up the proper display ordering and resolutions on my 2 external monitors outside of the gnome display settings.

I still have a bit of a scale issue, but I think that will be tolerable until I find a better way to set scale percentage.

edited Oct 25 '17 at 21:49

Zanna

69,223
56
216
327

answered Oct 24 '17 at 13:04

Karl Carpenter

91
1
4

After using arandr to config xrandr, my Apply button now appears when I make changes in gnome-control-center displays. Makes me wonder if the upgrade from 17.04 left something new for gnome unconfigured or a missing file? Maybe I wouldn't have had this issue with a clean install? – Karl Carpenter Oct 24 '17 at 13:22
I did a clean install of 17.10 and I've the same issue when I connect 2 screens (1 to the HDMI port and 1 through the Dell USB-C Adaptor). Having only 1 ext screen connected still works fine. Your workaround works fine! – maasg Oct 30 '17 at 09:43
This is not really a solution :-( and it doesn't seem to be working for me – LetynSOFT Feb 16 '18 at 13:53

Fred Dubois · Answer 2 · 2017-11-20T18:15:26.423

(Update: This solution doesn't work in the end (see my first comment) but I'm leaving it here in case it can maybe help someone.)

I have the same issue, what I did was edit ~/.config/monitors.xml and change the scale from 1 to 2 for my monitor that had 4k resolution (the laptop's display, which is also the primary monitor in my case):

<logicalmonitor>
  <x>0</x>
  <y>0</y>
  <scale>2</scale> <!-- Scale was originally set to 1 -->
  <primary>yes</primary>
  <monitor>
    <monitorspec>
      <connector>eDP-1-1</connector>
      <vendor>SHP</vendor>
      <product>0x1476</product>
      <serial>0x00000000</serial>
    </monitorspec>
    <mode>
      <width>3840</width>
      <height>2160</height>
      <rate>59.996623992919922</rate>
    </mode>
  </monitor>
</logicalmonitor>

I then logged out and back in. Opening the display pannel now shows scale set to 200% for my 4k monitor.

Strike that, it actually didn't solve my issue. Well it did for my main monitor but the other monitors seem to also have scale == 2 :/ Actually also used ARandR in the end.... — Fred Dubois, Nov 20 '17 at 18:14
