I’m looking to install a projector in my basement and the most ideal configuration would be to mount it to the ceiling with a ceiling mount. However, the “sweet spot” location for hanging (in considering distance to the projector screen) falls underneath a bulkhead that houses AC and heating ductwork, and I don’t detect any beams with my stud finder.

I obviously don’t want to mount directly into the ductwork for many reasons (vibration, projector misalignment due to changing temperatures expanding/contracting, air leaks, etc.).

What are some other options? The projector is only 8 lbs., so can I use construction adhesive (like liquid nails) to adhere a piece of wood onto the drywall, and then mount the projector into the wood? The projector mount includes 2.5” lag bolts for mounting...

I’ve also considered a projector shelf on the back wall but given the distance to the screen, the projector lens should be 28.24” from the back wall - so that would be a very deep (and perhaps custom built) shelf.

Here’s a picture of the area. Thanks!

enter image description here

isherwood
  • 119,766
  • 7
  • 148
  • 349
littleK
  • 197
  • 1
  • 7
  • 1
    The drywall of the bulkhead has to be screwed in to something. There **is** framing in there. Instead of a stud locator, try a strong magnet to locate the drywall screws. – Steve Wellens Dec 23 '20 at 16:41
  • The zoom should be able to handle a measly extra foot of throw. Get it atop a bookcase or something before you decide to start drilling holes. Ideally you set it low so you don't have to keystone the crap out of it. – Mazura Dec 24 '20 at 05:54

1 Answers1

4

There should be some sort of framing around the ductwork although I would bet it's just a 1x2 board and not suitable for lag bolts.

I would suggest to do the shelf idea or mount it from the ceiling.

enter image description here

MonkeyZeus
  • 15,488
  • 2
  • 21
  • 57
  • 1
    Thanks. I think I'll have to go with the shelf option as the real ceiling is too far forward. – littleK Dec 23 '20 at 18:52
